East Palm Canyon Perspective - Master Plan Full Build Out
Existing Worship Space - Community Center - Mikvah
A Proposed Remodel, Addition, and Mikvah for a Chabad Palm Springs
A Master Plan for a Jewish Community addressing the programatic requirements of a center of Jewish life and education providing a range of religious and community services to the residents of the Coachella Valley. This Master Plan addresses these needs in a proposed remodel of the existing structure, and additions to include worship, multipurpose, study, lodging, and social spaces. A significant component of the plan is the construction of a Mikvah.
Phase One - Proposed Mikvah
North Elevation - Utensil wash - Entry - Entry Garden
Side Street Elevation
Axio Plan Entry Garden, Entry, (clockwise) Gate, Changing, Mikvah, return to Changing. Also Washroom, Private Changing, Water Storage, Mechanical & Laundry
Mikvah Entry Exterior
Mikvah Entry
Changing Room - Shower Room Beyond
Mikvah - Immersion Pool
Phase Two - Community Center, Lodging Palm Canyon Perspective
Phase Two - Palm Canyon Elevation
Phase Two - View from the North West
Phase Two - View from the North East - Lodging on the Second and Third Levels
Phase Two - Ground Level Plan
Phase Two - Second Level Plan
Phase Two - Third Level Plan
Phase Two - Roof Terrace - Aerial Axio
Video of Palm Canyon Elevation
Video - Mikvah walk through
Phase Two - Courtyard - with Coffee Shop beyond on Ground Level, Multi Purpose Room on Second Level
Phase Two - Portico Looking toward hand washing at the Entry
Phase Two - Portico looking toward the Utensil Washing
Phase Two - Multi Purpose Room with Library beyond
Phase Three - Worship Space Remodel (to the left)
Phase Three - Palm Canyon Drive Elevation
Phase Three - View from the North West
